Engineered for both high-performance and efficiency, the EcoMax brings a noticeable upgrade to both operators and customers. The advanced blade design moves air more efficiently, cutting through water quickly and producing a quieter sound profile than traditional blowers.
By optimizing airflow, the axial fan design uses less energy without sacrificing performance- helping lower operating costs while supporting more sustainable operations. It's an ideal solution for washes located near residential neighborhoods, where noise levels matter just as much as results. You get the drying power you need, but the disruption you don't.
Built at our Wisconsin facility out of durable stainless steel and HDPE, construction of the EcoMax offers exceptional resistance to corrosion, moisture, and chemicals commonly found in car wash environments. Built to perform, designed to last, and engineered with both operators and surroundings in mind, EcoMax sets a new standard for car was drying technology.
Efficiency That Performs
-
90% less sound energy
-
Over 50% quieter to the human ear
-
Ideal for residential and noise-sensitive locations
-
Significantly better working environment
-
High efficiency motors (+95.6%)
-
6.9% less energy used per hour of use
-
Runs cooler, longer motor life, less downtime
-
VFD required
-
120 HP system saves 6.88 kWh per hour of operation
-
Reduce hz for even more energy savings
Features and Benefits
15 HP OMEC PM Motors
208 V FLA
36.6 amps
230 V FLA
33.1 amps
460 V FLA
16 amps
SF amps
1.15 60 Hz
RPM
3600
Air Velocity
147mph
TEFC Motors
3 Phase
Frame Size
215 Tc
Total Weight
377 lbs
EcoMax Specifications
-
HDPE producer housing colors available
Blue
Black
Granite
Gray
Red
Green
Yellow
Quieter Operation
60 HP
Distance From Bay
60 HP
(4-15 HP)
10 ft
84 dB
20 ft
78 dB
30 ft
74 dB
40 ft
72 dB
50 ft
70 dB
90 HP
Distance From Bay
90 HP
(6-15 HP)
10 ft
86 dB
20 ft
80 dB
30 ft
76 dB
40 ft
74 dB
50 ft
72 dB
105 HP
Distance From Bay
105 HP
(7-15 HP)
10 ft
86 dB
20 ft
80dB
30 ft
77 dB
40 ft
74 dB
50 ft
72 dB
120 HP
